  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Originally posted by cobblerdave View Post
    Gudday
    Those doors are looking great
    I don't think that technically that's a blast door. From what I believe a blast door seals the entrance and controls the exit of smoke and entrance of air. Using the door outside the oven entrance still allows the oven to breath the way it naturally does but stops the heat reflecting out. I might be drawing to fine a distinction there, but I don't think so.
    Like the aluminum checker plate . I'm warming to that stuff, it should make a more permanent replacement for my plywood experimental I'm thinking
    Thanks
    Dave
    Perhaps I should have said sudo blast door. Using a door in this way does have some of the benefits of a purpose built blast door. Its stops any smoke exiting the front when first starting a fire, and does a good job at funnelling air into the base of the fire. You are right though its not 100% a blast door.

    I used the checker plate because its easy to work with and light. I used a jigsaw to cut it to shape. The plate purchased was 600 wide, and a perfect width for my entry. And don't look to shabby.

    Cheers

    Leave a comment:


  • cobblerdave
    replied
    Re: New 36inch castable build in Brisbane

    Gudday
    Those doors are looking great
    I don't think that technically that's a blast door. From what I believe a blast door seals the entrance and controls the exit of smoke and entrance of air. Using the door outside the oven entrance still allows the oven to breath the way it naturally does but stops the heat reflecting out. I might be drawing to fine a distinction there, but I don't think so.
    Like the aluminum checker plate . I'm warming to that stuff, it should make a more permanent replacement for my plywood experimental I'm thinking
    Thanks
    Dave

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Finished the external weather door to keep rain and splashes out.

    The last photo is my insulating window door used as a blast door, its moved to the front of the entry and has a couple of inched gap around the sides and top.

    Leave a comment:


  • oasiscdm
    replied
    Re: New 36inch castable build in Brisbane

    I was thinking of obtaining combustion heater glass and driving it been 2 layers Calsil.
    Some how.

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Hi Colin,

    I found the glass lid on ebay.com.au.
    Store home: Search results for: 'Raco 20cm Glass Lid'

    The diameter is 20cm. The central hole was only about 8mm, I used a diamond drill bit to drill it out to fit the thermometer thread.

    Tile Drill Bit Qep 10mm Diamond I/N 6820162 | Bunnings Warehouse

    I hope it does not crack from the centre out. I went a l little fast and have a small chip. Not sure, it will matter but I would keep the centre hole as clean as possible. If you decide to do this. Use water with it....

    Steve.

    Leave a comment:


  • oasiscdm
    replied
    Re: New 36inch castable build in Brisbane

    Hi Brissie

    Nice work i'm working on the same thing as we speak 3 doors.

    I'm sticking with the stainless and looking at isolation methods and making the solid door so I can interchange various insulation types.

    I too am looking at the glass door cooking option. I like the thermometer in the glass door. Can I ask was that a frypan lid?

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Solid door

    Ply glued to 75mm hebel with aluminium foil hot face, and aluminium flashing sides.

    The third door will be continued. It needs a few thing done to finalise.

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Window door continued.

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Made 3 doors over the last day and a half.

    I changed my original door design, from all SS to mainly Hebel construction. This is because of the heat conductivity of metals. I have used aluminium which is a very good conductor only on the sides because its easy to work with. Its used sparingly. Aluminium foil is also used because it also reflects heat. High temperature silicon was used to glue most of it together, a few SS screws and pop rivets were use on the edges to hold the edging on.

    The designs attempts to protect the hebel to an extent, from both heat and abrasion. Only time will tell if it works out. Hopefully it won't fall apart any time soon.

    1) window door for baking
    2) solid door heat retention
    3) Weather/Blast door, mainly to keep the weather out. Stop water drops getting into the cal sill board.

    The window door first. Its constructed with a number of layers. I used a stainless steel oven face first, a air gap ,aluminium foil, then the hebel, then a ply exterior.

    At the base the ply sits on top aluminium angle. The SS on the hot face is bent under and up so a recess is created over the heat break in the hearth tiles. So the heat break is maintained.

    Aluminium flashing was used to wrap around hot face entry. The aluminium is 99% not an alloy, so is malleable easy to bend around the SS.

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    I have a few posts, The first is some Pizza.

    Baccia cheese used on a few pizzas was fantastic. We have been experimenting with a few cheeses from an Italian shop Penissi near the Gabba.

    It has a soft creamy texture.

    Leave a comment:


  • cobblerdave
    replied
    Re: New 36inch castable build in Brisbane

    Gudday Steve
    I too tried the sour dough bit but didnt like the smell of it after feeding it for a week. Recon its just too hot and humid and I give it another go when the wheather turns colder
    Made some interesting dough replacing the water with beer. Gave you an interesting sourdough effect and the dough rise the same. Just use XXXX gold. Not my idea read it somewhere maybe on the forum. Just use room temp beer, not to high an alcohol content or to bitter a hop and it works well.
    You can't tell its got beer in it as I got it past the child bride, she still thinks it the sour dough experiment and she is not to know any different.
    Regards dave

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Originally posted by cobblerdave View Post
    Gudday Brissie
    Yes I did your link
    I only mad it worse
    So I decided heat of no heat I'm going to cook this!
    I flashed the oven up ... A one hour burn .. Hoping that I had enough heat
    Sunday afternoon .. The dough goes off like a started roo ,and I put it in the fridge to settle it down.
    Did all the fold thing and threw it in.... What tha.
    [ATTACH]41062[/ATTACH]
    It's not the best , but the son has eaten it all,
    Thanks Dave
    Yes I didn't use to much para cheese not to salty
    Good work, It looks good. And your son obviously reckons so... It was lucky I got it mostly okay first time.

    There is so much you can do with a WFO. I attempted some sourdough pizza's on Sunday after a couple of weeks cultivating the starter. Pizza's where just passable, not good. I don't think I will try this again. I do want to try some bread, But will make a door first that's not a Lego kit (5 pieces).

    Cheers,

    Steve
    Last edited by brissie; 01-09-2014, 06:54 AM.

    Leave a comment:


  • cobblerdave
    replied
    Re: New 36inch castable build in Brisbane

    Originally posted by brissie View Post
    Hi guys,

    Its easy to make. I made the pizza dough the night before, let it rise a bit and put it in the fridge. I think the flavour improves if you make the dough the night before the bake. I generally do this when making pizza's.

    Check google tortano - Google Search

    It looks like you can add any filling, but fillings packed with flavour work the best. It can be eaten warm or cold, I think it tastes the best when still warm.

    I used parmesan cheese, but when I make it again I would used a third parmasen and 2 thirds a softer cheese. It was packed with flavour but a bit salty. Reducing the parmasen should fix this.

    Happy cooking

    Update : I think you could used any tin or no tin. But it does look good in the traditional shape.

    Bundt tins, are used so the centre of a round cake cook, depending in the cake recipe. Some cakes need this because they might not cook in the middle.
    Gudday Brissie
    Yes I did your link
    I only mad it worse
    So I decided heat of no heat I'm going to cook this!
    I flashed the oven up ... A one hour burn .. Hoping that I had enough heat
    Sunday afternoon .. The dough goes off like a started roo ,and I put it in the fridge to settle it down.
    Did all the fold thing and threw it in.... What tha.
    Click image for larger version

Name:	image.jpg
Views:	1
Size:	855.6 KB
ID:	303165
    It's not the best , but the son has eaten it all,
    Thanks Dave
    Yes I didn't use to much para cheese not to salty

    Leave a comment:


  • Greenman
    replied
    Re: New 36inch castable build in Brisbane

    They are called Bundt Pans.

    I had a look at YouTube and if you are fluent in Italian you will get plenty from there. Watching the pictures and with some guesswork and the grasp of a couple of words of Italian you can get the idea.

    Looks like something interesting to make.

    Leave a comment:


  • brissie
    replied
    Re: New 36inch castable build in Brisbane

    Hi guys,

    Its easy to make. I made the pizza dough the night before, let it rise a bit and put it in the fridge. I think the flavour improves if you make the dough the night before the bake. I generally do this when making pizza's.

    Check google tortano - Google Search

    It looks like you can add any filling, but fillings packed with flavour work the best. It can be eaten warm or cold, I think it tastes the best when still warm.

    I used parmesan cheese, but when I make it again I would used a third parmasen and 2 thirds a softer cheese. It was packed with flavour but a bit salty. Reducing the parmasen should fix this.

    Happy cooking

    Update : I think you could used any tin or no tin. But it does look good in the traditional shape.

    Bundt tins, are used so the centre of a round cake cook, depending in the cake recipe. Some cakes need this because they might not cook in the middle.
    Last edited by brissie; 12-30-2013, 04:56 AM.
